TPC Superb Air Oil-Less Air Compressor, 1 x 2.0 HP motor, 10 Gal, 3-4 User (220V) # DC8124
Description
SUPERB Air Compressor
1 x 2 HP, 220V
Model: DC8124
Shipping Dimensions: L X W X H -- 30" X 29" X 37"
DESCRIPTION
The TPC SUPERB Air Oil-Less Air Compressors meet the high standards of the DENTAL professionals, providing the reliability you need from a brand you can trust. The new motor design delivers a reduced noise with a 5-year warranty. The membrane Air drying system efficiently filters out compressed Air contaminants and moisture from the compressed Air. Purge tank removes residual humidity in the compressor following each cycle.
*SuperbAIR Air Compressors not to be used for CAD / 3D printers*
FEATURES:
• NEW Motor Design to REDUCE Noise & Increase Reliability
• QUIET Operation
• UNIQUE Membrane Air Drying System to Remove Moisture from Compressed Air
• Dry Air PREVENTS Bacterial Growth
• Air if Filtered to 0.01 micron keeping 99.9997% of Air Contaminants out of your Air System
• ENERGY EFFICIENT Thermally Protected Motors
• SUPERB Air Oil-Less Compressors are AVAILABLE in Single or Twin Heads
• 5-Year WARRANTY
SPECIFICATION:
MODEL
USER CAPACITY
CDFM @ 80PSI
# OF HEADS
TOTAL HP
VOLTAGE
LINE FREQUENCY
BREAKER AMPS
DBA
TANK CAPACITY
SIZE (HXWXD)
DC8124
3 Users
9.8
1
2
230V
60Hz
15
20
72
10 Gallons
29x28x23
OPTIONS
Control Panel 3 Button Vac, Air, Water
Control Panel 4 button Vac, Vac, Air, Water
Air Compressor and Vacuum pump stacking rack
MODEL
SVCP-3
SVCP-4
STACK
TPC SUPERB Air Compressor: DC8124 vs DC8228
Core Difference (Short Answer)
DC8124: single-head, single motor → mid-capacity
DC8228: dual-head, dual motor → higher capacity, redundancy
Key Specifications
| Feature | DC8124 | DC8228 |
|---|---|---|
| Compressor heads | 1 head | 2 heads |
| Motors | 1 motor | 2 motors |
| Horsepower (total) | 2.0 HP | 4.0 HP (2 × 2.0 HP) |
| Tank size | ~10 gal | ~20 gal |
| Air output (CFM @ ~80 PSI) | ~9.8 CFM | ~20 CFM |
| Recommended users | 3–4 | 7–8 |
| Oil-less | Yes | Yes |
| Redundancy | No | Yes (can run on one head if the other fails) |
| Electrical load | Lower | Higher |
| Physical size / weight | Smaller / lighter | Larger / heavier |
